Konica KM1024LNB 42PL Printhead Description
The Konica Minolta 1024 printhead dramatically increases productivity due to its 1024 nozzles, enabling 72 mm wide printing. This unit is equipped with twice the number of nozzles as the Konica Minolta 512 printhead, providing the high density required to achieve 72 mm print width.
The Konica Printhead 1024 printhead, equipped with a new control IC, can print up to 8 ink droplet sizes. This provides better control over printed images, reproducing smooth color gradations and precisely matched tones.
The increase in Konica printhead 1024 greyscale levels reproduces rich tones and subtle gradations, making the printheads even more attractive for existing and new printing applications.
Konica KM1024LNB 42PL Printhead Specifications
| Technology | Piezo Drop-On-Demand (Shared wall 3 cycle) |
| Native Resolution | 180 dpi ¡Á 2 lines = 360 dpi |
| Cal. Droplet Size | 42 picoliters |
| Tot. Amount of Nozzles | 512 nozzles ¡Á 2 lines = 1024 nozzles |
| Nozzle Spacing | 70.5 ¦Ìm (141 ¦Ìm ¡Á 2 lines) |
| Print Width | 72 mm |
| Firing Frequency | 6.7 kHz |
| Ink Compatibility | Solvent- and oil-based ink |
| Heater | Not integrated |
| Grey-scale | 8 levels |
